Storm @Twitter

Storm is a realtime fault-tolerant and distributed stream data processing system.

Storm is currently being used to run various critical computations in Twitter at scale, and in real-time.

（1）Scalable.The operations team needs to easily add or remove nodes from the Storm cluster without disrupting existing data flows through Storm topologies.

（2）Resilient.Fault-tolerance is crucial to Storm as it is often deployed on large clusters, and hardware components can fail.

（3）Extensible.Storm topologies may call arbitrary external functions, and thus needs a framework that allows extensibility.

（4）Efficient.Since Storm is used in real-time applications; it must have good performance characteristics.

（5）Easy to Administer.The operational team needs early warning tools and must be able to quickly point out the source of problems as they arise.

    1.S4 2.MillWheel 3.Samza 4. Spark Streaming 5.Photon

    1. Shuffle grouping, which randomly partitions the tuples.

    2. Fields grouping, which hashes on a subset of the tuple attributes/fields.

    3. All grouping, which replicates the entire stream to all the consumer tasks.

    4. Global grouping, which sends the entire stream to a single bolt.

    5. Local grouping, which sends tuples to the consumer bolts in the same executor.

    A topology can be considered as a logical query plan from a database systems perspective. As a part of the topology,the programmer specifies how many instances of each spout and bolt must be spawned.

    At least once semantics guarantees that each tuple that is input to the topology will be processed at least once.

    With at most once semantics, each tuple is either processed once, or dropped in the case of a failure.

Configuration	Configuration details	Result
1	Use an existing Zookeeper cluster at  Twitter that was also being used by  many other systems inside Twitter	Quickly exceeded the amount of  clients that this Zookeeper  cluster could support
2	Identical to the first one, except with  dedicated hardware for the Zookeeper  cluster	Improved the number of workers  processes and topologies that run  in Storm cluster , but quicklyhit a  limit at around 300 workers per  cluster
3	Changed the Zookeeper hardware and  configuration again: We used  database class hardware	Scaled to approximately 1200  workers
4	Changed the Kafka Spout code to  write its state to a key-value  store , also changed the  Storm core	In favor of high availability and  high write performance

Storm Overheads:

The experiment	Experimental  environment	Support  message  reliability	Input  consumption (msgs/sec)	CPU  utilization
1	Write a Java program that did not use Storm1 machine	no	300K	700%
2	Storm topology 1 machine	no	300K	660%
3	Storm topology 3 machine	yes	300K	924%

Conclusion 1: Mitigated the concerns regarding Storm adding significant overhead compared to vanilla Java code that did the same computation.

Conclusion 2: Storm CPU costs related to the message reliability mechanism in Storm are nontrivial .

Max Spout Tuning:

Storm topologies have a max spout pending parameter.

Problem ：right value for this max spout pending parameter.

Solution：auto-tuning algorithm.

4、Conclusions and Future Work

Storm is a critical infrastructure at Twitter that powers many of the real-time data-driven decisions that are made at Twitter.

1.Automatically optimizing the topology statically and re-optimizing dynamically

2.Add exactonce semantics

3.Improve the visualization tools, improve the reliability of certain parts

4.Provide a better integration of Storm with Hadoop

5.Support a declarative query paradigm for Storm that still allows easy extensibility.
